Getting Started

Prerequisites

• Lens Studio 5.12.1 or later
• An OAuth2 provider
• Spectacles App

Auth Kit uses OAuth2 authentication flow through the Spectacles App, which requires a mobile device for testing. Deep link redirects are handled by the Spectacles App and are not supported in the Lens Studio editor.

Auth Kit is exclusively designed for Spectacles Lenses and uses the Spectacles App for OAuth2 authentication. It is not supported for Snapchat Lenses.

About Auth Kit

Auth Kit enables secure user authentication with external services through the OAuth2 protocol, with all authentication flows handled by the Spectacles App.

To start building authenticated experiences in your Lens using Auth Kit, follow the instructions below to start a new project or update an existing project in Lens Studio.

Package Resources

The Auth Kit package includes the following resources when imported into your Asset Browser:

• OAuth2 Core: Main OAuth2 class and authentication logic optimized for Spectacles
• Token Management: Secure token and TokenManager classes with Spectacles App integration
• Deep Link Integration: Seamless OAuth2 redirect handling via Spectacles App deep links

Required Redirect URI

Auth Kit requires different redirect URIs for development and production environments. Configure your OAuth2 provider accordingly.

Finding Your Lens ID

When publishing your Lens, you'll need to replace [LENS_ID] with your actual Lens ID. You can find this in the My Lenses Portal after submitting your Lens for review.

Standard OAuth2 Providers

Development Environment:

https://www.spectacles.com/deeplink/specslink/oauth2redirect/unsecure

Published Lens:

https://www.spectacles.com/deeplink/specslink/oauth2redirect/[LENS_ID]

Replace [LENS_ID] with your actual Lens ID when publishing.

Google OAuth2

Google OAuth2 requires special setup and uses a different URI format with a custom scheme.

Setup Steps:

1. Register your app as an "iOS application" in the Google Cloud Console
2. Set Bundle ID to com.snap.spectacles when creating the iOS client
3. Use the custom scheme format for redirect URIs as shown below

URI Format:

• Development: com.snap.spectacles:/specslink/oauth2redirect/unsecure
• Published Lens: com.snap.spectacles:/specslink/oauth2redirect/[LENS_ID]

Implementation Example:

const googleOAuth = new OAuth2({
  clientId: 'YOUR_GOOGLE_CLIENT_ID',
  authorizationUri: 'https://accounts.google.com/o/oauth2/v2/auth',
  tokenUri: 'https://oauth2.googleapis.com/token',
  redirectUri: 'com.snap.spectacles:/specslink/oauth2redirect/LENS_ID', // For published lens
  // redirectUri: 'com.snap.spectacles:/specslink/oauth2redirect/unsecure' // For development
});

Starting a New project

Importing Auth Kit into a New Lens Studio Project

To start building an authenticated Spectacles Lens from scratch using Auth Kit, follow these steps:

1. Create a new Lens Studio project or open an existing Spectacles project.

2. Import the Auth Kit package from Asset Library. Follow this guide to learn how to install packages from the Asset Library.

3. Create a new TypeScript script in your project and import the OAuth2 class from Auth Kit:

import { OAuth2 } from 'AuthKit.lspkg/Core/OAuth2';

4. Configure your OAuth2 provider with the required settings for Spectacles App integration:

const oauth = new OAuth2({
  clientId: 'YOUR_CLIENT_ID', // Required: OAuth2 client ID
  authorizationUri: 'https://example.com/oauth/authorize', // Required: Authorization endpoint
  tokenUri: 'https://example.com/oauth/token', // Required: Token exchange endpoint
  refreshUri: 'https://example.com/oauth/refresh', // Optional: Token refresh endpoint
  clientSecret: 'YOUR_CLIENT_SECRET', // Optional: For confidential clients
  redirectUri:
    'https://www.spectacles.com/deeplink/specslink/oauth2redirect/LENS_ID',
});

Basic Usage

The following examples are code snippets and may not be completed and won't run as-is.

Setting Up Auth Kit with OAuth2

import { OAuth2 } from 'OAuth2Kit.lspkg/Core/OAuth2';

// Create OAuth2 instance configured for Spectacles App integration
const oauth = new OAuth2({
  clientId: 'YOUR_CLIENT_ID', // Required: OAuth2 client ID
  authorizationUri: 'https://example.com/oauth/authorize', // Required: Authorization endpoint
  tokenUri: 'https://example.com/oauth/token', // Required: Token exchange endpoint
  refreshUri: 'https://example.com/oauth/refresh', // Optional: Token refresh endpoint
  clientSecret: 'YOUR_CLIENT_SECRET', // Optional: For confidential clients
  redirectUri:
    'https://www.spectacles.com/deeplink/specslink/oauth2redirect/LENS_ID',
});

Starting Authentication via Spectacles App

try {
  // Start the OAuth2 authorization process through Spectacles App
  const token = await oauth.authorize('read write profile');

  if (token) {
    print('Successfully authorized via Spectacles App!');

    // Get access token for authenticated API calls
    const accessToken = await oauth.getAccessToken();

    // Make authenticated requests to your OAuth2 provider
    const response = await fetch('https://api.provider.com/user', {
      headers: {
        Authorization: `Bearer ${accessToken}`,
      },
    });
  }
} catch (error) {
  print(`Authorization failed: ${error.message}`);
}

Checking Authorization Status

// Check if user is currently authorized through Auth Kit
if (oauth.isAuthorized) {
  print('User is authenticated via Spectacles App');
  // Access token will be automatically refreshed if needed
  const accessToken = await oauth.getAccessToken();
} else {
  print('User needs to authenticate through Spectacles App');
  // Initiate OAuth2 authorization flow via Spectacles App
  await oauth.authorize('required scopes');
}

Sign Out

// Clear stored tokens and sign out user from Auth Kit
oauth.signOut();

Configuration Options

When creating an OAuth2 instance for Auth Kit, you can configure the following options:

Option	Type	Required	Description
clientId	string	✅	Your OAuth2 client ID from the provider
authorizationUri	string	✅	OAuth2 authorization endpoint URL
tokenUri	string	✅	OAuth2 token exchange endpoint URL
refreshUri	string	?	Token refresh endpoint (defaults to tokenUri)
clientSecret	string	?	OAuth2 client secret (for confidential clients)
authenticationType	string	✅	Flow type: "code" (recommended for Spectacles App)

Testing Requirements

Auth Kit is designed exclusively for Spectacles and requires specific setup for testing:

Prerequisites for Testing

1. Spectacles Device: Auth Kit is not compatible with Lens Studio Editor - you must test on actual Spectacles
2. Spectacles App: Ensure the Spectacles App is installed and ready on your mobile device
3. Mobile Device: The Spectacles App handles OAuth2 redirects and requires a connected mobile device
4. Network Connection: Both Spectacles and your mobile device need internet connectivity

Testing Steps

1. Deploy your Lens to Spectacles using Lens Studio
2. Open the Spectacles App on your mobile device
3. Launch your Lens on the Spectacles device
4. Initiate authentication through your Lens interface
5. Check your mobile device and a notification will appear to verify the OAuth2 connection
6. Complete the authentication flow by following the prompts in the Spectacles App

Error Handling

Auth Kit provides detailed error messages for common OAuth2 scenarios:

try {
  await oauth.authorize('read write');
} catch (error) {
  print(`Auth Kit OAuth2 error: ${error.message}`);
}
